Relay Test Sets

Test Sets For Any Relay Protection Scheme

  • Performs Standard Relay Calibration And Verification Testing Of High Burden And Microprocessor Relays
  • Analog Testing Of 1 A And 5 A Protection Devices
  • Performs State Simulation And Transient Testing
  • Tests 0.2-Class Metering CTs And Transducers
  • Implements End-To-End Testing Of Communications-Based Schemes With GPS Time Syncing
  • Maximum Of 12 Sources (Six Voltage, Six Current) Configurable For Bench Testing And Proof-Of-Concept Testing For Complicated Relaying Schemes
  • Delivers Full VA Power With Resistive, Inductive And Capacitive Loads At Maximum Current Rating (6 X 35, 3 X 70, 1 X 210 A)
Data Sheet
Doble F6895
  • The F6895 option includes a GPS antenna/receiver with 100ft. cable. It is used with the F6885 GPS Receiver Interface to provide a GPS signal to the test instrument
Data Sheet
Doble F8300
  • Differential testing with 3 phases of 300 V L-N & 6 currents
  • Generation station testing with 4 phases of 150 V L-N
  • Robust transmission scheme testing and transformer differential with 4 phases of 150 V L-N, 8 programmable logic I/O, 6 currents
  • Ph-Ph transformer protection testing with 12 logic I/O, 4 voltages at 150 V, 4 currents
  • Transformer differential testing with 4 phase at 150 V for testing transmission protection
Data Sheet
  • Large 10.1” display
  • Six AC/DC Currents
  • Four AC/DC Voltages
  • 12 Contact / 0-250Vrms Voltage inputs
  • Four contact outputs
  • Transducer voltage/input
  • GPS input
Data Sheet
  • The engineer’s toolbox for all single-phase relay testing
  • Standalone functionality
  • Rugged and reliable for field use
Data Sheet
  • Plug-and-play solution for quick and easy testing of any recloser control
  • Rugged design and usable in harsh weather conditions
  • GPS synchronized automated distribution scheme tests
  • Easy-to-use software to wirelessly control ARCO 400, no special training required
Data Sheet
  • Highly versatile test set for all generations of relays and protection schemes
  • Ten binary inputs
  • Six current outputs
  • IEC 61850 capable
  • Provided with Test Universe Software
Data Sheet
  • Control one OMICRON test set at a predetermined point in time (triggering the starting point of a test process)
  • Synchronize the starting point of a test process of two or more OMICRON test sets
  • Accurately time-stamp data captured by an OMICRON test set
Data Sheet
  • Connection Of Third-Party Devices To The CMC Low Level Signal Outputs
  • Connection Of OMICRON Amplifier Units To Any Signal Sources
  • Easy Access To The Low Level Signals Between The CMC And A CMS 356
Data Sheet
Powerent SPRT
  • Fully isolated and adjustable AC & DC voltage, current output, short circuit, overload, and over-range automatic protection
  • DC:0-220V Amplifier output, short circuit, overload, over-range automatic protection
  • AC:0-120V Amplifier output, short circuit, overload, over-range automatic protection;0-8A Amplifier output, short circuit, overload, over-range automatic protection
  • Maximum output current:0-150A
  • LCD screen. AC and DC voltage and current values, stopwatch, potential, contact status
  • Internal electric stopwatch, can work with live contacts, potential up to 250V, two-way measurement
Data Sheet
  • Connect The SEL 4388 Mirrored Bits Tester To The Serial Cable Or Fiber-Optic Transceiver Connected To An SEL Relay Or Processor Mirrored Bits Communications Port
  • Verify The Addressing And Communications Parameters For The Channel Through The LCD Display
  • Observe The State If Each Transmitted (TMB) And Received (RMB) Bit On LEDs.
  • Transmit Test Bits Using SEL-4388 Pushbuttons
Data Sheet
