Insulation Resistance

Megohmmeter or ‘Megger’ Tests the Effectiveness of Electrical Insulation

AEMC 6505

Test Insulation On Cables, Transformers, Motors, Generators, Insulators And Wiring Installations
High Resistance Or Absorption Tests
Timed Resistance Measurements
Dielectric Absorption. Ratio (DAR) And Polarization Index (PI) Tests
Test Old Or Water Damaged Installations
Motor Insulation Resistance Measurements

AEMC 6555

True Megohmmeter®
Fixed or programmable test voltage from40 V to 10 kV/15 kV
Wide measurement range from 10 kΩto 25 TΩ/30 TΩ
5 mA short circuit current• Step and Ramp voltage testing
Automatic calculation of DAR / PI / DD /∆R(ppm/V) ratios
Large, backlit graphical LCD screen with digital display, bar graph and R(t)+V(t), I(t)and I(V) graphs
Multiple test modes: voltage ramp and step with “Burn-In”, “Early-Break”and “I-Limit” modes
Three filter settings to optimize measurement stability

FLUKE 1550C

Test Voltages up to 5 kV
Selectable test voltages in 50 V steps from 250 V to 1000 V, and 100 V steps above 1000 V
CAT III 1000 V, CAT IV 600 V safety rating
Capacitance and leakage current measurement
Ramp function for breakdown testing
Resistance measurements up to 2 TΩ

FLUKE 1555

Test voltages to up 10 kV
Warning function alerts the user that line voltage is present and gives the voltage reading up to 600 V AC or DC for increased user safety
Selectable test voltages in 50 V steps from 250 V to 1000 V, and 100 V steps above 1000 V
Capacitance and leakage current measurement
Ramp function for breakdown testing
Resistance measurements up to 2 TΩ

MEGGER MIT 1025

Measures up to 20 TΩ
PI, DAR, DD, SV and ramp test
Advanced memory with time/date stamp
CATIV 600 V safety rating
Offering CAT IV, the MIT1025 is compact, light 10 kV insulation resistance tester for the diagnostic testing and maintenance of high voltage electrical equipment

MEGGER MIT 1525

Maximum test voltage of 15kV
Auto IR, DAR, PI, Step Voltage, DD and Ramp
Measures up to 20TΩ
Improved productivity – operate from line power/mains if battery dead

MEGGER MIT 515

Insulation resistance up to 10 TΩ
Li-ion battery for up to 6 hrs continuous testing
Advanced memory, on screen recall and real time clock for date / time stamped results

MEGGER MIT 525

Insulation resistance up to 10 TΩ
Li-ion battery for up to 6 hrs continuous testing
Advanced memory, on screen recall and real time clock for date / time stamped results
